Step Sequence

Numbered steps that take turns, with the media beside them cross-fading.

From the Findit template — see it in context
Open living room with a long grey sofa

Installation

$ npx shadcn@latest add https://framebrick.co/r/step-sequence.json

Usage

import { StepSequence } from "@/components/ui/step-sequence";

<StepSequence
  label="How it works"
  steps={[
    { value: "brief", title: "Tell us what you need", description: "…", media: <Image src={brief} alt="" fill /> },
    { value: "tour", title: "Tour the shortlist", description: "…", media: <Image src={tour} alt="" fill /> },
  ]}
/>

Props

PropTypeDefaultDescription
steps{ value, title, description?, media? }[]—The steps, in order. `media` fills the panel beside them.
labelstring—Accessible name of the sequence.
valuestring—Active step (controlled).
defaultValuestringfirst stepStep that starts active (uncontrolled).
onValueChange(value: string) => void—Called when another step becomes active.
intervalnumber5000Milliseconds a step stays active; 0 turns the rotation off.
  • The steps are a tab list: arrow keys, Home and End move between them, and the media is their panel. The tabs are the list's own children — wrapping them in <li> breaks the pattern.
  • An inactive step sits at 70%, not Framer's 50%, which dropped its text to 2.1-3.7:1 in every theme. Its description carries its own darker tone, because the row's 70% multiplies whatever colour it has.
  • The rotation pauses while the pointer is over it or something inside has focus, so a step cannot change mid-sentence.
  • With reduced motion it does not rotate at all — a timer is neither a transform nor a size animation, so MotionConfig would not stop it.

AI prompt

Paste into v0, Lovable, Bolt or Claude to rebuild this component in your own project.

Create a React + Tailwind CSS + Motion (motion/react) component called StepSequence.
- Two columns from 1024px up (stacked below): on the left numbered steps ("01." in a 32px column with a 2px rule
  running to the next step, title font-medium, description text-sm text-muted-foreground); on the right a rounded-lg
  panel holding one media element per step, absolutely stacked.
- The active step is at opacity 1, the others at 0.5; the active media is at opacity 1, the others at 0.
  Both animate with a spring (bounce 0, duration 0.4s).
- Every `interval` ms (default 5000) the next step becomes active, wrapping around; clicking a step activates it at once.
- Controlled (value + onValueChange) or uncontrolled (defaultValue, first step by default).
- Accessibility: role tablist with aria-orientation vertical, each step a role tab with aria-selected and a roving
  tabIndex, arrow keys / Home / End move and select, the media panel is role tabpanel with aria-labelledby.
- Pause the rotation while the pointer is over the component or focus is inside it, and do not rotate at all when
  useReducedMotion() is true.
